5in1 Dimming Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM LED Driver, 12V 60W

Model	VBD-012-060C2DM5i1
Input Voltage	100-277V AC
Input Current	0.9A
Frequency	50-60 Hz
Power Factor	>0.95
Output Voltage	12V DC
Output regulated Current	5A
Output Power	60W max
Dimmable	Yes (Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM)
IP Rating	IP67 (Dry, Damp and Wet Locations)
Dimensions	189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
Class Certification	Class 2
Certifications:

Applicable for dry, damp, and wet locations

Compatible with Forward-Phase, Magnetic low Voltage & Triac dimmers



Features:

• Class 2 LED driver supporting Triac/Phase/MLV/ELV/0-10V/Potentiometer/10V PWM dimming methods
• Input voltage range: 100-277V AC, input current: 0.9A, frequency range: 50-60 Hz
• Power factor greater than 0.95 for efficient power usage
• Output voltage: 12V DC, regulated output current: 5A, maximum output power: 60W
• Dimmable driver suitable for use in dry, damp, and wet locations with IP67 rating
• Dimensions: 189mm x 94.57mm x 40.80mm (7.45in x 3.75in x 1.6 in)
• Certified by UL and FCC for safety and compliance.
