OTM-TD20 Constant Voltage LED Driver, 0-10V Dimming LED Driver 12V 18W

Model	OTM-TD20
Input Voltage	100-130V AC
Input Current	0.24A
Frequency	50-60Hz
Efficiency	>80%
Output Voltage	12V DC
Output regulated Current	1500mA
Output Power	18W max
Power Factor	>0.95
Dimmable	Yes (0-10V Dimming)
IP Rating	IP20
Ambient Temperature (Ta)	40°C
Case Temperature (Tc)	80°C
Class Certification	Class II/ SELV
Dimensions	66.16mm x 20.15mm (2.6 in) Dia x (0.8 in) Depth
Certification

Compatible with 0-10V Dimmers

Applicable for Dry and Damp locations

Short circuit and Overload Protected

Class II Power Supply, Double-layer insulation

Easily fits in a 1-Gang Standard Box or Single Gang Box



Features:

• Model number: OTM-TD20
• Constant voltage LED driver with 0-10V dimming support
• Input voltage range: 100-130V AC
• Input current: 0.24A
• Frequency: 50-60Hz
• Efficiency >80%
• Output voltage: 12V DC
• Regulated current: 1500mA
• Maximum power output: 18W
• Power factor >0.95
• IP rating: IP20
• Ambient temperature: up to 40°C
• Maximum case temperature: 80°C
• Class II/SELV certified for protection against electric shock
• Dimensions: 66.16mm x 20.15mm (2.6 in) diameter x (0.8 in) depth
• ETL certified for safety and performance standards in the US and Canada.
